Project Description

GF200 Bubble Gum Center-filled Die-formed Lollipop Production Line


The production line is a complete plant for making different kinds of die-formed chew gum filled lollipops.

Main Technical Parameters

Production capacity   ( kg/h)200~250
Drum running speed(n/min)         0~20r/min
Diameter of each lollipop Available(mm)25~32mm(round)
Length of stick available(mm)60~100mm
Diameter of the stick available(mm)Dia.3.2~4.0mm
Steam consumption    (kg/h)300
Steam pressure        (Mpa)0.2~0.6
Electric power needed22kw/380V
Conditions needed for the cooling stage:
1.Room temperature(℃)20~25
2.Humidity (%)<55
Length of the whole line   (m)15m
Gross weight           ( Kgs)Approx.5000

Lollipop Samples

The Machinery to Produce Bubble Gum Lollipop

Candy Cooker

Sugar Dissolving Cooker

  • Full Stainless Steel 304 whole compact set for the dissolving system(sugar dissolving cooker, gear pump, and storage tank are installed in a compact SS frame body), it saves the space, and is easy for maintenance.
  • Improved connection makes no leakage of the steam.
  • Stainless steel syrup pump replaces the old steel pump, more durable and hygiene.
LX400 Vacuum Cooker With Vacuum Pump

LX400 Vacuum Cooker With Vacuum Pump

  • Feed pump
  • Coil type cooker
  • Vacuum chamber
  • Vacuum pump
  • 2 sets of rotating cooker
  • Food standard Stainless Steel 304 made
Cooling Table

Cooling Table

  • Food Standard Stainless Steel 304 made
  • Size: 1800x800x1000mm
Gum Mixer

Gum Mixer

  • Food standard tainless Steel 304 made
  • Stirring speed:
    n1= 42 r/min
    n2= 26 r/min
GF-Gum Extruder

Gum Extruder

  • Food standard stainless steel 304 made
  • Screw type
  • Nos of screw: 2
  • Drive power:3kw
Batch Roller

Batch Roller

  • Heater Power: 1.2KW
  • Motor: 0.75KW
  • Dimension: 3400×700×1400mm
  • Weight: 500KGS
Rope Sizer

Rope Sizer

  • Motor: 0.75KW
  • Dimension: 1010×645×1200mm
  • Weight: 320KGS
Uniplast Lollipop Die Forming Machine

Uniplast Lollipop Die Forming Machine

The machine can make different sizes of ball-type lollipops, also can make the central- filling lollipops. It is stepless-speed adjusted, and combines the process of syrup auto-feeding, auto stick-insertion, lollipop forming and outgoing in one machine. It can be used for making different sizes of lollipops

TG-Lollipop Die Mould

Lollipop Die Mould

  • Made of high quality steel, long-shelf life;
  • High precision
GF200-Cooling tunnel with refrigerator

Cooling Tunnel With Refrigerator

  • Cooling Layers: 3-7layers
  • Transporting belt speed: Max.5.5m/min
  • Speed of sieve plate swing: 76times/min
  • Power of convey motor: 0.5kw
  • Power of main motor: 1.5kw
  • Power of Compressor: 7.5kw
  • Cooling water inlet Temperature: <25℃
  • Fan motor power: 2×0.75kw
