TB300 Chocolate Single-Twist Packing Machine

Description

TB300 chocolate single-twist packing machine is twist packaging for cone, rectangle and roundness chocolate. film delivery structure use servo motor device, also can match the color code positioning. By the delivery conveyor, chocolate could be delivered to the packing machine. The packing speed is based on the product quantity controlled by the auto system. The feeding system could be both automatic and manual.

Packaging Type

Chocolate Dimensions

Rectangle Shape Chocolate
A:15-50mm
B: 10-40mm
C: 8-40mm
(customer made by special size)

Rectagle shape chocolate Dimensions

Cone Shape Chocolate
A:15-40mm
B:4-20mm
C:12-38mm
(customer made by special dimensions)

Cone shape chocolate Dimensions

Technical Parameters

Model	TB300
Packing speed	100~300bag/min
Voltage	3phase/380V (adjustable according to local voltage)
Power	4.5KW
Packing film width	50-130mm
Packing film Length	40-130mm
Max external diameter	300mm
