Project Description

Description

The production line is a fully automatic/semi-auto plant for making different kinds of die-formed hard candies.

Main Technical Parameters

ModelTG200TG300
Production capacity150~200kg/h300kg/h
Weight of CandyMax 6gMax 6g
Steam consumption kg/hN/M500kg/h
Steam pressureN/M0.8-1.0Mpa(8-10bar)
Electric power needed20KW34KW
Conditions:
1.Room temperature20~25℃20~25℃
2.Humidity (%)55%55%

Hard Candy Samples

Get In Touch

    The Machinery to Produce Hard Candy

    Candy Cooker

    Sugar Dissolving Cooker

    • Full Stainless Steel 304 whole compact set for the dissolving system(sugar dissolving cooker, gear pump, and storage tank are installed in a compact SS frame body), it saves the space, and is easy for maintenance.
    • Improved connection makes no leakage of the steam.
    • Stainless steel syrup pump replaces the old steel pump, more durable and hygiene.
    LX400 Vacuum Cooker With Vacuum Pump

    LX400 Vacuum Cooker With Vacuum Pump

    • Feed pump
    • Coil type cooker
    • Vacuum chamber
    • Vacuum pump
    • 2 sets of rotating cooker
    • Food standard Stainless Steel 304 made
    Cooling Table

    Cooling Table

    • Food Standard Stainless Steel 304 made
    • Size: 1800x800x1000mm
    Jam Center-Filling Machine

    Jam Center-Filling Machine

    • Food standard tainless Steel 304 made
    • Volume:50Liter
    • Double-jacket
    • Stirrer:0.75kw
    TG- Powder Feeding Pump

    Powder Feeding Pump

    • Food standard Stainless Steel 304 made
    • Power: 1.1kw
    • Screw type
    Batch Roller

    Batch Roller

    • Heater Power: 1.2KW
    • Motor: 0.75KW
    • Dimension: 3400×700×1400mm
    • Weight: 500KGS
    Rope Sizer

    Rope Sizer

    • Motor: 0.75KW
    • Dimension: 1010×645×1200mm
    • Weight: 320KGS
    TG Hard Candy Uniplast Die Forming Machine

    Uniplast Die Forming Machine

    • High stability and easy for the operation;
    • Moulds are made of high quality steel, long-shelf life, high precision;
    • Uniplast dies change can be completed within several minutes
    TG- Hard Candy Die Mould

    Hard Candy Die Mould

    • Made of high quality steel, long-shelf life;
    • High precision
    TG PLC Control System

    PLC Control System

    Full PLC control and touch screen provide full process operation. Recipe management and alarm handling; Accurate control of the product dimensions and weight

    Cooling Tunnel With Refrigerator

    Cooling Tunnel With Refrigerator

    • Cooling Layers: 3-7layers
    • Transporting belt speed: Max.5.5m/min
    • Speed of sieve plate swing: 76times/min
    • Power of convey motor: 0.5kw
    • Power of main motor: 1.5kw
    • Power of Compressor: 7.5kw
